THIS IS RACING

Panigale V4 R

HIDE

240.5 hp.
16,500 rpm.
This is Racing

Ducati presents the new Panigale V4 R: the bike that adopts technical
solutions previously reserved for MotoGP and WorldSBK Championship.

The closest production model to a competition bike ever.

Price starts at INR 69,99,000 (Ex-Showroom India)

Watch the unveiling

DUCATI WORLD PREMIÈRE

Episode 4 of the Ducati World Première showcases the flagship model of the Panigale family. Discover all the details.

GO TO THE PREMIÈRE

Pure racing spirit

The road version of the Panigale V4 R undergoes significant development, upgrading in all areas to be faster on the track and even more race-oriented.

ENGINE

The heart of the Panigale V4 R is the new 998 cc Desmosedici Stradale R, an engine capable of reaching a maximum engine speed of 16,500 rpm in sixth gear (16,000 in the other ratios) and delivering a maximum power of 218 hp at 15,500 rpm (Euro-5 compliant*), absolute benchmark values in the panorama of supersports bikes of the same displacement. *Only in countries where Euro 5 applies

DISCOVER MORE

ELECTRONICS

Race-oriented electronics

The greater effectiveness of the new Panigale V4 R in circuit use is also obtained thanks to the adoption of all the electronic evolutions already introduced on the Panigale V4 '22 and '23, with the expansion and evolution of the Power Modes, new “Track Evo” display on the dashboard, engine maps with calibration dedicated to each single gear, refinements to the Ducati Traction Control and the Ride By Wire system, but also the adoption of the Engine Brake Control EVO 2 strategy, the new strategy for the DQS and the cooling fan control update.

DISCOVER MORE

CHASSIS

Improved track-feeling

To increase nimbleness, rider feeling and grip, the chassis follows the evolutionary direction traced by the Panigale V4/V4 S with the 2022 model, while maintaining fully mechanical suspension adjustment. At the front, the Öhlins NPX25/30 pressurized fork increases its travel by 5 mm compared to the previous "R". This technical solution, combined with an Öhlins TTX36 shock absorber and a standard adjustment of the swingarm pivot to the +1 position, increases the rear height by 20 mm. In this way, a higher centre of gravity is achieved and therefore greater nimbleness in corner entry and changes of direction.

DISCOVER MORE

AERODYNAMICS

Aerodynamic development

The aerodynamic package has been revised with a view to greater efficiency: the new two-element wings (main + flap) guarantee the same aerodynamic load, but are more compact and thinner (respectively by 40% and 50%).

DISCOVER MORE

DUCATI CORSE OIL

A special oil developed by Shell in collaboration with Ducati Corse.

The new performance oil** is based on the use of racing-type additives. In combination with the racing exhaust the maximum power output of the Panigale V4 R can reach an extraordinary 240.5 hp.

Download Panigale V4 R Brochure

Download the brochure and discover all you need to know about the Panigale V4 R.

DOWNLOAD THE BROCHURE

**Timing and availability of the product may vary depending on the country.

***Fitting charges are not included

Contact dealer

Racing technology

The Panigale V4 R adopts technical solutions reserved for MotoGP and Superbikes, such as "gun drilled" titanium connecting rods and pistons with DLC surface treatment.

Other interventions involve pistons with new geometry, a more aggressive intake cam profile, adoption of the same gear ratio used by bikes competing in World Superbike, and a new lighter dry clutch.

Greater effectiveness in track use is also achieved through electronic evolutions, such as the expansion and evolution of the Power Modes, the new Track Evo display on the dashboard, engine maps with dedicated calibration for each individual gear, refinements to the DTC and Ride By Wire throttle system, but also the Engine Brake Control EVO 2, the new strategy for the DQS, and the updated cooling fan control.

The Panigale V4 R also adopts a new throttle control that improves the rider's feeling when opening and managing the throttle.

PANIGALE V4

Type: Desmosedici Stradale 90° V4, counter-rotating crankshaft, 4 Desmodromic timing, 4 valves per cylinder, liquid-cooled
Displacement: 1,103 cc
Power: 158.5 kW (215.5 hp) @ 13,000 rpm
Torque: 123.6 Nm (91.2 lb-ft) @ 9,500 rpm
Wet weight no fuel: 189 kg (417 lb)

Tech Specs

Type

Panigale V4 R
Displacement

998 cc
Bore x Stroke

81 x 48.4 mm
Compression Ratio

14.0:1
Power

160.4 kW (218 hp) @ 15,500 rpm
152.2 kW (207 hp) @ 13,500 rpm (USA/CAN/MEX)
174 kW (237 hp) @ 15,500 rpm with full racing exhaust*
Torque

111.3 Nm (82 lb-ft) @ 12,000 rpm
111.1 Nm (82 lb-ft) @ 12,000 rpm (USA/CAN/MEX)
118 Nm (87 lb-ft) @ 12,250 rpm with full racing exhaust*
Fuel Injection

Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies with aerodynamic valves. Variable length intake system
Exhaust

4-2-1-2 system, with 2 catalytic converters and 4 lambda probes

Gearbox

6 speed with Ducati Quick Shift (DQS) up/down EVO 2
Primary drive

Straight cut gears; Ratio 1.80:1
Ratio

1=36/15 2=34/17 3=33/19 4=32/21 5=30/22 6=27/22
Final drive

Chain; Front sprocket 15; Rear sprocket 42
Clutch

Hydraulically controlled slipper dry clutch. Self bleeding master cylinder.

Frame

Aluminum alloy "Front Frame" with optimized stiffnesses
Front suspension

Fully adjustable 43 mm Öhlins NPX 25/30 pressurized fork with TiN treatment.
Front Wheel

3-spokes forged aluminum alloy 3.50" x 17"
Front Tyre

Pirelli Diablo Supercorsa SP 120/70 ZR17
Rear suspension

Fully adjustable Ohlins TTX 36 unit with hydraulic spring preload adjuster. Aluminium single-sided swingarm. Adjustable pivot position +/- 3 mm
Rear Wheel

3-spokes forged aluminum alloy 6.00" x 17"
Rear Tyre

Pirelli Diablo Supercorsa SP 200/60 ZR17
Wheel Travel

125 mm (4.9 in) - 130 mm (5.1 in)
Front Brake

2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Stylema® (M4.30) 4-piston callipers with Bosch Cornering ABS EVO. Self bleeding master cylinder.
Rear Brake

245 mm disc, 2-piston calliper with Bosch Cornering ABS EVO
Instrumentation

Last generation digital unit with 5" TFT colour display

Wet weight no fuel

184 kg (406 lb)
179 kg (395 lb) with full racing exhaust*
Seat Height

850 mm (33.5 in)
Wheelbase

1,471mm (57,9 in)
Rake

24,5°
Trail

100 mm (3,94 in)
Fuel Tank Capacity

17 l - 4.49 gallon (US)
Number of Seats

Single seat

Safety Equipment

Riding Modes, Power Modes, Cornering ABS EVO, Ducati Traction Control (DTC) EVO 3, Ducati Wheelie Control (DWC) EVO, Ducati Slide Control (DSC), Engine Brake Control (EBC) EVO 2, Auto tyre calibration
Standard Equipment

Ducati Power Launch (DPL), Ducati Quick Shift (DQS) up/down EVO 2, Full LED lighting with Daytime Running Light (DRL)**, Öhlins steering damper, Quick adjustment buttons, Lithium-ion battery, Auto-off indicators, Racing style handle grips, Chain guard, Marchesini forged aluminum wheels, Carbon fiber front mudguard, Carbon fiber heatshield, Carbon fiber wings, Billet aluminum steering stem with bike number, High-flow air filter
Provided Equipment

Machined mirror block-off plates*, License plate mount removal plug*, Ducati Data Analyser+ (DDA+) with GPS module
Ready for

Ducati Multimedia System (DMS) and anti-theft

Warranty

24 months unlimited mileage
Maintenance service intervals

12,000 km (7,500 mi) / 12 months
Valve Clearance Check

24,000 km (15,000 mi)

Standard

Euro 5
CO2 Emissions

185 g/km
Consumption

8 l/100km
Emission Notes

Only for countries where Euro 5 standard applies.

NOTES

*This product is intended for vehicles used only in closed-course circuit. Operation on public roads is prohibited by law.
**Bike specifications and equipment may vary from market to market. Please refer to your local dealer for further information

ENGINE

Desmosedici Stradale R: pure racing architecture

An engine created to compete in Superbike championships and developed in close synergy with Ducati Corse. Read the in-depth article to find out the main new features.

GO TO ENGINE

New electronic setup

Within the riding modes, the new Power Mode logic has been adopted with dedicated calibrations for the Desmosedici Stradale R engine. There are four engine strategies: Full, High, Medium, Low. Full and Low are newly designed, while the High and Medium configurations have been revised.

ELECTRONICS

Top of the range electronic set-up

New controls in the Dashboard interface and operation of Power Modes: find out about the main updates in the electronic package.

GO TO ELECTRONICS

Power at first sight

Every technical detail has been thought out and designed to enhance the pure racing feel of the bike.

Discover the range of Ducati Performance accessories and refine the sporty soul of your Panigale V4 R.

CONTAC US

Contact dealer

The circuit. Its natural
habitat.

Even faster. Even more racing. The track soul of the new Panigale V4 R makes it the perfect bike for your track days. The new livery is inspired by MotoGP in its graphics and conveys the racing spirit from the very first glance, incorporating white number plates with the number "1" prominently displayed.

A magical combination of
beauty and technology

Discover the range of Ducati Performance accessories designed to enhance the look and performance of your new Panigale V4 R.

EXHAUST

Akrapovič titanium exhaust

With an Akrapovič titanium full exhaust system with double under-seat silencer, which improves the already reduced weight/power ratio of the V4 R thanks to a weight saving of 5 kg compared to the standard system and the increase in power up to 237 hp. The exhaust is supplied with dedicated mapping with which all DTC, DWC, DPL and DSC parameters are adjusted to the new performance of the bike.

CONFIGURE NOW

PIT STOP

Pit Stop Accessory Package

The Pit Stop accessory package offers tyre warmers and garage stands to enable you to approach your track sessions in the best of conditions. Those wishing to use Slick or Rain tyres can choose the DTC EVO 3 software, which introduces the specific calibrations of the electronic controls.

CONFIGURE NOW

CARBON

Carbon fiber components

To further embellish the Panigale V4 R it is also possible to adopt one or more of the carbon fibre components for the superstructures, from front and rear mudguards to protections for the frame, swingarm, sprocket and crankcase, even arriving at details such as the ducts for the cooling of the front brakes, which improve performance on the track and make braking more efficient and consistent.

CONFIGURE NOW

Magnesium rims

Further lightening is possible by fitting the magnesium rims, which guarantee a saving of 0.7 kg (- 10%) compared to the already light forged original equipment rims, improving all aspects of dynamics and above all nimbleness in corner entry and in changes of direction.

Aluminum adjustable footpegs

To better adapt the riding position, adjustable aluminium rider footpegs are available, developed by Ducati Corse in collaboration with Rizoma. They have articulated brake and shift pedals to minimize the risk of breakage in the event of a slip and use the standard DQS, which can be configured as either a traditional or inverted/racing shifter.
