All Mountain E-Mtb by Ducati

The Ducati MIG-S is an agile, high-performance and fun all-mountain bike, designed to tackle any trail and ensure maximum fun in any conditions. New in aesthetics with an unprecedented sporty livery designed by Aldo Drudi and with the high-performance Shimano EP8 motor with 85Nm of torque and updated components.

The new adjustable RockShox suspension, the SRAM NX 12-speed rear derailleur for even more precise and reliable shifting, and powerful and modular SRAM 4-piston brakes you'll appreciate from the very first ride. Now more than ever, the MIG-S is ready to accompany you on all your off-road adventures.

CONTACT US

Shimano EP8 engine

A benchmark in the category thanks to its low weight of 2.6 kg, its compact size and a Q factor of only 177 mm. With a maximum torque of 85 Nm and an assistance ratio of up to 400%, this drive unit ensures great pedalling power with always fluid, direct and natural delivery, for complete control of the vehicle. Combined with the Shimano E-tube Project App, the EP8 system allows advanced levels of customization to adapt the character of the engine to your needs. All our e-mtb come with two pre-set profiles: "long ride" to favour long distances and "fast ride" for greater engine responsiveness.

Aluminium frame

Forged and CNC machined parts with variable thickness hydroformed tubes. The geometries of the frame, with a 66° head angle, an elongated top tube and a 74.7° vertical seat tube, ensure pedalling efficiency and control of the vehicle even on the most technical passages.

RockShox suspension

The new air suspensions (RockShox 35 RC fork and RockShox SuperDeluxe R shock absorber) are adjustable and have 150 mm of travel at the front and 140 mm at the rear, ideal for safely tackling any type of path and obstacle.

Main components

High-level like the KS dropper post with remote handlebar control, the powerful and modular SRAM Guide T 4-piston brakes and the SRAM NX 12-speed rear derailleur (11-50T) that ensure great performance and safety in all conditions.

Low centre of gravity

The 630Wh battery positioned below the down tube, as well as being quick and easy to remove, ensures a very low centre of gravity, maximizing handling and stability.

Tyres and rims

Differentiated Thok e-plus rims with Pirelli Scorpion Enduro S 29" x 2.6 SmartGrip Hyperwall tyres at the front and Pirelli Scorpion E-MTB S 27.5" x 2.6 at the rear. They allow you to overcome the most difficult of obstacles with momentum and always have maximum grip on any terrain.

MY22

Frame: Alloy frame 6061 forged and CNC parts, hydroformed tubes
Engine: Shimano Steps EP8 (250 Watt – 85 Nm - 2.6 kg)
Battery: Shimano – 630 Wh (semi-integrated)
Fork: Front: RockShox 35 RC Air, 150 mm travel, custom tuned
Rear shock: Rear: RockShox Deluxe Select R air, 140 mm travel, custom tuned, metric 210 x 55 mm
Brakes: Sram Guide T - 4 calipers – 203 mm rotor
Rear derailleur: SRAM NX 12 speed (11-50)

TECH SPECS

Frame

Alloy frame 6061 forged and CNC parts, hydroformed tubes

Display

Shimano - SC-E7000 LCD display with remote control
Battery

Shimano – 630 Wh (semi-integrated)
Brakes

Shimano – 630 Wh (semi-integrated)
Rear derailleur

SRAM NX 12 speed (11-50)
Shift lever

SRAM SX 12 speed
Handlebar

Thok 780 mm alloy oversize, 35 mm section, 20 mm rise
Wheels

Thok e-plus - 29” front (Small size 27.5") - 27.5” rear
Tires

Front: Pirelli Scorpion Enduro S, TR, SmartGrip, HyperWall 29" x 2.6 (Small size 27.5" x 2.6) Rear: Pirelli Scorpion E-MTB S, TR, SmartGrip, HyperWall, 27.5” x 2.6Front: Pirelli Scorpion Enduro S, TR, SmartGrip, HyperWall 29" x 2.6 (Small size 27.5" x 2.6) Rear: Pirelli Scorpion E-MTB S, TR, SmartGrip, HyperWall, 27.5” x 2.6
Saddle

Ducati Fit - hollow Cr.Mo rail

Shimano Etube Project App

Thanks to the Shimano Etube Project App, it is also possible at any time to adapt the character of the motor to your needs even via your smartphone wirelessly, by adjusting maximum torque and assistance timing.
